Stryker 150A-G
Engine Driven Welder Generator
Gas engine-driven power in a compact, portable frame.
- Output Range
- 30A – 150A
- Part Number
- STR-150A-G
- 30A – 150A output
- 100% duty cycle @ 25°C
- Stryker S225 gas engine
- 3.2 kW auxiliary power
Overview
The 150A-G is designed for high portability and mobility with high power and a high duty cycle in its category, aimed at smaller welding operations. It is designed for welding materials up to 1/4 to 3/8 inch thickness (thicker if beveled with a root pass and fill welding).
With a full tank of gas the welder can be used for 2+ hours continuously; with a spare fuel tank a full workday of welding can be achieved. Because of its mobility it can sit close to the welding location — stay aware of engine exhaust fumes and never use it in an enclosed space.
Auxiliary power output is available to run hand tools, lighting and other items that assist the welding operation. It is not designed as a general-purpose generator for high power use.
In the field
Specifications
Part Number STR-150A-G
Welding (IEC Rating)
- Current Range
- 30A – 150A
- Duty Cycle
- 100% @ 25°C
Engine
- Manufacturer
- Stryker – Gas
- Model
- S225
- Emissions Rating
- US EPA
- Power
- 4.0 kW / 5.4 HP
- Speed
- 3800 RPM
- Oil Capacity
- 0.6 L / 0.16 G (US)
Auxiliary Generation
- Current Type
- AC
- Frequency
- 60 Hz
- Output Voltage
- 1 @ 120V – 20A
- Maximum Power
- 3.2 kW
General & Dimensions
- Fuel Capacity
- 3.6 L / 0.95 G
- Open Circuit Voltage
- 75 OCV @ 3600 RPM
- Height
- 474 mm / 18.6 in
- Width
- 445 mm / 17.5 in
- Depth
- 410 mm / 16.1 in
- Dry Weight
- 35 kg / 77 lbs
Specifications are drawn from the official Stryker America specification sheet and are subject to change. Refer to the product owner's manual for complete operating information.
